AX20 RGB

Dimensions:

• 358 x 207 x 451 mm (D × W × H)

Form Factor:

• Mid Tower

Materials:

• Steel + Plastic

Motherboard Support:

• ATX, Micro-ATX, ITX

Front I/O Ports & Controls:

• Power Button
• Reset Button
• 2 x USB 2.0
• 1 x USB 3.0
• MIC / HD-AUDIO

Side Panel:

• Tempered Glass

Drive Bays & Expansion Slots:

• Expansion Slots: 7
• 3.5" / 2.5" Convertible Bays: 2 / 1
• 2.5" Drive Bays: 2

Cooling & Fan Support:

• Fan Support:

  • Front: 3 x 120mm / 2 x 140mm
  • Top: 2 x 120mm
  • Power Supply Shroud: 2 x 120mm
  • Rear: 1 x 120mm

• Included Fans (Depending on Variant):

  • AX20: 3 x 120mm RGB fixed-mode fans (Front)
  • AX20 Elite: 3 x 120mm RGB fixed-mode fans (Front) + 1 x 120mm RGB fixed-mode fan (Rear)

Radiator Support:

• Front: 120mm / 140mm / 240mm / 280mm

Clearance & Compatibility:

• Max GPU Length: ≤ 270mm
• Max CPU Cooler Height: ≤ 155mm
• Max PSU Length:
  • ≤ 170mm (with HDD)
  • ≤ 295mm (without HDD)

Additional Features:

• Dust Filter: Front
• Net Weight:
  • 4 Kg (AX20)
